OVERVIEW

MSquare offers a silicon-proven ONFI 5.0 PHY IP which supports all modes of the Open NAND Flash Interface (ONFI) 5.0 Specification. ONFI is an interface connecting external flash particles (NAND Flash) and internal flash controller (NAND Controller), which is used in Solid State Drive (SSD) and embedded memory (eMMC) products. To facilitate customer implementation, the MSquare ONFI 5.0 PHY features support for expandable channels and customizable CE/RB Pad Numbers.

HIGHLIGHTS

Compliant with ONFI 5.0 specification

Supports NV-DDR2 mode

Supports NV-DDR3, NV-LPDDR4, and max rate up to 2400MT/s

Supports PHY Independent TX/RX Training mode

Supports DFI with 1:1/1:2 ratio mode

Supports self-test mode with built-in BIST

Supports loopback test with built-in PRBS

Supports ODT programmable and ZQ calibration

Integrated low-jitter PLL & DLL
